NZXT N9 X870E Black WiFi7 Motherboard
In stock
SKU
N9-X87XT-B1
The N9 X870E delivers cutting-edge performance in a sleek design, making it an ideal foundation for modern AMD® gaming PCs. Built for the latest AMD® Ryzen™ processors, it features overclocking-ready power, optimized thermals, and PCIe 5.0 support, plus high-speed Wi-Fi 7, 5GbE, and USB 4 connectivity. The full-metal cover with subtle RGB lighting adds a touch of sophistication to any build.
Specs you want in ALL NZXT system
MD® AM5 Socket: Ready for AMD® Ryzen™ 9000, 8000, and 7000 series desktop processors.
Superior Power: A robust 20+2+1 power phase design with 110A SPS and an 8-layer, low-loss 2-oz copper PCB ensure exceptional stability and overclocking potential.
Advanced Cooling: Stay cool under pressure with a VRM heatsink array with thermal pads, dual PWM fans, and fins, plus dedicated heatsinks and thermal pads for all M.2 slots.
PCIe® 5.0 Expansion: One PCIe® 5.0 x16 slot for next-gen GPUs and one PCIe® 3.0 x16 slot for additional high-speed expansion cards.
DDR5 Memory: Four dual-channel DIMM slots support DDR5 RAM speeds of 8000+ MT/s, delivering faster multitasking and improved system responsiveness.
High-Speed Storage: Four M.2 slots, including one PCIe® 5.0 and three PCIe® 4.0, deliver ultra-fast storage speeds and load times—all with quick-release latches.
Next-Gen Connectivity: USB 4 (40 Gbps), Wi-Fi 7, and 5GbE deliver blazing-fast data transfers and ultra-low latency networking.
Sleek & Stylish: A premium full-metal cover conceals the PCB for a clean, modern aesthetic, enhanced by onboard customizable RGB lighting.
| Full technical specification | |
|---|---|
| Chipset | AMD X870E |
| Part Number | N9-X87XT-B1 |
| Interfaces & Connections | 2x USB4 with DisplayPort 1.4 (40Gb/s, ASMedia ASM4242, iGPU), 5x USB-A 3.1 (10Gb/s), 3x USB-A 3.0 (5Gb/s), 2x USB-A 2.0 (480Mb/s), 1x toslink S/PDIF Out (Realtek ALC4082), 2x 3.5mm jack (Realtek ALC4082), 1x RJ-45 (5GBase-T, Realtek RTL8126), 2x ante |
| Expansion Slots Total | 1x PCIe 5.0 x16, 1x PCIe 3.0 x16 |
| Networking Type | Wi-Fi 7 (WLAN 802.11a/b/g/n/ac/ax/be, 2x2), Bluetooth 5.4 | 1 x Realtek 5.0G LAN |
| Audio | Realtek ALC4082 Audio Codec - High Definition Audio 2/4/5.1/7.1-channel |
| RAM Max Size | 192 |
| Service & Support Type | 4x DDR5 DIMM, Dual Channel, UDIMM (Non-ECC), max. 192GB (UDIMM) |
| Features | All black PCB! audio+solid capacitors, Diagnostic LED (LED indicators), Diagnostic LED (segment indication), I/O-shield integrated, 4x M.2-passive cooler |
| RAM Type | DDR5 |
| Socket | AM5 |
| Motherboard Form Factor | ATX |
| Free Shipping | No |
